Factory Free sample 1,2,4 cores fiber optic FTTH drop cable

Name: Factory Free sample 124 cores fiber optic FTTH drop cable
Brand: ODM/OEM
Price: 0.04 USD

China Factory Free sample 1,2,4 cores fiber optic FTTH drop cable factory

Model Number : FTTH drop cable

Place of Origin : China

Brand Name : ODM/OEM

Packaging Details : 2KM/ Drum

Supply Ability : 1000 Kilometer/Kilometers per Quarter

MOQ : 1000 meters

Price : $0.04 - $0.09/meters

Certification : RoHS, CE

Payment Terms : T/T, Western Union

Type : Fiber Optic Cable

Use : FTTH

Product name : FTTH drop cable

Fiber count : 1~4 fibers

Fiber Type : singlemode(G652D,G657A) or multimode

Diameter : 2.0*3.0 mm

Jacket color : Black or customize

Material : LSZH

Operating temperature : -40℃- +70℃

Warranty : 20 years

Certificate : ISO,ROHS

Application : FTTX , outdoor

No. of Fiber : 1-4

Single-Mode Fiber : G655,G652D,G657A

Multi-Mode Fiber : OM1.OM2.OM3.OM4.OM5

Contact Now

Factory Free sample 1,2,4 cores fiber optic FTTH drop cable

FTTH indoor cable has a much greater bandwidth to carry data and less susceptible to interference thancommon indoor fiber cables and it's ideal for indoor cabling, end users directly cabin, and access network.

Features

Small diameter and light weight, water-resistant, soft and bendable, easy to deploy and maintenance
Meet the requirement of thunder-proof, anti-rodent or waterproof
Good to use for fiber to the home last mile solution

Application

Outdoor aerial application
Used in the FTTH projects
High speed optical routes in building

Technical parameters

Cable Construction Parameter:

Fiber Core	1	2	1	4
Cable Dimension(mm)	2.0×5.0	2.0×5.0	2.0×5.3	2.0×5.3
Cable Weight(kg/km)	9	10	11	12

Mechanical & Environmental Performance:

Max Load (N)	Long Term	60	60	60	60
Max Load (N)	Short Term	120	120	120	120
Bending Radius(CM)	Dynamic	30
Bending Radius(CM)	Static	15

Drop cables are located on the subscriber end to connect the terminal of a distribution cable to a subscriber’s premises. They are typicality small diameter, low fiber count cables with limited unsupported span lengths, which can be installed aerially, underground or buried. As it is used in outdoor, drop cable shall have a minimum pull strength of 1335 Newtons according to the industry standard. Drop cables are available in many different types. Flat Type Drop Cable, also known as flat drop cable, with a flat out-looking, usually consists of a polyethylene jacket, several fibers and two dielectric strength members to give high crush resistance. Figure-8 Aerial Drop Cable is self-supporting cable, with the cable fixed to a steel wire, designed for easy and economical aerial installation for outdoor applications. Round Drop Cable usually contains a single bend-insensitive fiber buffered and surrounded by dielectric strength members and an outer jacket, which can provide durability and reliability in the drop segment of the network.

FEATURES

Good mechanical and environmental characteristics; Flame retardant characteristics meets the requirements of relevant standards; The mechanical characteristics meets the requirements of relevant standards; Soft, flexible, easy to splice, and with big capacity data transmission; Meet various requirements of market and clients.

Factory Free sample 1,2,4 cores fiber optic FTTH drop cable

Main Products

Our Company

We are a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter.

With years of experiences in the fiber optic industry, our factory is fully equipped over 3500 square meters and more than 23 non dust production lines .About 200 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 8 production lines for standard jumper and 8 PLC Splitter production lines.

The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on.

All of our optical products are RoHS compliant and also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, Looking forward to cooperate with you.

INNOVATIVE TECHNOLOGY

We always learn new technology by investing in production facilities, engineering process control systems, and talent development to maintain our status as a leading fiber optic connection solutions.

Packing & Delivery

Sample

Within 1-2 working days

Wholesale orders

3-7 working days according various quantities

FAQ

1. How many staff's we have?
Answer: About 200 well-trained staff and engineers.

2. What's our main products?
Answer: We dedicate to the developing, production, marketing of the Fiber Optic Cable,
Indoor/Outdoor Patch Cord, Splitter, Adapter, Attenuator, and so on.

3. What is the area of the factory?
Over 3500 square meters
More than 18 non dust productions lines in total
4 production lines for Fiber Optic Cable
2 high standard MPO/MTP Jumper assembly lines
8 production lines for standard Jumpe
4 PLC Pplitter production lines

4. What certificate we have?
Answer: ISO 9001: 2015, RoSH, CE, High and New Tech Enterprise Certficate.
